Drive Shaft Axle Shaft for Hyundai
Hyundai
Drive Shaft : 1.Type of Tube or Pipe: triangular profile tube; lemon profile tube
3.End Yokes: shear bolt torque limiter, spline type torque limiters, ratchet type torque limiter, clutch type torque limiter, etc.
4.Plastic Safty Guard: yellow or black.
5.Overall length & working length: according to your requirement
6.With CE Certificate
Technical Parameters for PTO Shafts with Splines
H1-QD-SP
H2-QD-SP
H3-QD-SP
H4-QD-SP
H5-QD-SP
Lowest Rotational Speed
540 R.P.M
Max.Torque
210NM
270NM
390NM
460NM
620NM
Max.Power Consumption
16HP
20HP
30HP
35HP
50HP
Max. Outreach
900
1150
1380
1620
2000
Min. Outreach
700
850
1010
1350
Weight
5KG
8.3KG
10KG
11KG
16.8KG
Spline (QD): 1 3/8Z6 Quick Release Yoke
1 1/2-Z8 Quick Release Yoke
SP: Diameter35mm / 30mm
Universal joint specifications that decide torque of a shaft:
Series
D*L(U. Joint)
Series 1#:
22*54 mm
Series 2#:
23.8*61.3 mm
Series 3#:
27*70 mm
Series 4#:
27*74.6 mm
Series 5#:
30.2*80 mm
Series 6#:
30.2*92 mm
