Hydraulic Brake Hose Saej1401 for Vw

Product Name:

Hydraulic Brake Hose Saej1401 for Vw

Application:

Vw

Product Description:

Brake tube:
SAEJ1401 GB16897-1997 MS263-49
act as apressure transmission for auto hyraulic pressure brake system.

Brake tube:

OEM  brake hose/braking hose/air brake hose/brake hose/hydraulic brake hose/auto brake hose

Namebrake hose
Uses: Act as apressure transmission for auto hyraulic pressure brake system.
Features: The hoses are braided with hign strength,manifold,polyester threads,and have such very good performances as the following,good flexibility bursting resistance,hign tensile strength,low swell increment of the internal volume,ozone resistance.low-temperatance,benging resistance,and good compatibility,with stable,safe andreliable braking effects.

Details Product Description.
OEM Hydraulic Brake Hose
Size and performace parameters information
    (I.D)mm   (O.D)mm   (Wall)mm  (WallDiff)mm  Expansion ml/m)Max  (Brust Press)Min.Mpa
1   3.2±0.2    10.5±0.2     3.65            0.25            1.08   1.38                         49.03
2   4.8±0.2    13±0.3        4.35            0.3              1.81   2.36                          34.5
3   6.3±0.2    15±0.3        3.75            0.3              2.69   3.84                          34.5m
